IAG Multi Functional Coating
IAG is a high performance, 100% solid multifunctional, solvent
free epoxy coating.
This cycloaliphatic amine poxy is a highly chemical and moisture
resistant material, which creates a protective barrier over a
variety of materials and surface conditions.
The highly versatile coating is exceptionally surface tolerant.
The lack of solvents allows the true chemical cure of IAG. This
feature combined with its excellent flow properties eliminates
any curling effect over surfaces where existing coatings or rust
where not completely removed. IAG may be applied over inorganic
zinc primers. IAG is very adherent to foam, lead, asbestos and
may be used as an encapsulant for these materials.
All federal and local regulations must be followed when IAG
is used in this manner.
The uniqueness of IAG as a maintenance coating allows it to
be used in place of more costly multi-coat systems.
IAG's multi functionality provides a very cost effective solution
for the protection of varied surfaces from moisture and corrosive
attack. IAG may be sprayed after proper mixing, using standard
airless equipment.
IAG may also be brushed, rolled or troweled.
It is recommended that surfaces should be prepared according
to applicable SSPC standards whenever possible. Please review
the application guide and material safety data sheets prior to
use.
TYPICAL PROPERTIES:
| Color |
gray |
| Viscosity @ 25 C |
7,000 |
| Tensile Strength |
7,600 psi |
| Open Time |
50 min |
| Operating Temp C |
-50 to + 140 |
| Hardness, Shore D |
78 |
| Mix ratio by weight (A:B) |
100:30 |
| Mix ratio by volume (A:B) |
100:35 |
ASTM 5894-96 Test Results:
|
Evaluation Method |
Panel 1 9mils |
Panel 2 10mils |
Panel 3 11mils |
|
ASTM 660-93:Checking |
No Visible Signs of Checking |
No Visible Signs of Checking |
No Visible Signs of Checking |
|
ASTM 714-87: Blistering |
10 |
10 |
10 |
|
ASTM D 1654-92: Corrosion Table
1 |
8 |
8 |
7 |
|
ASTM D 3359-02: Adhesion, Method A |
5A |
5A |
5A |
|
ASTM D 4214-98: Chalking, Method
A |
No. 8 |
No. 8 |
No. 8 |
IAG Multifunctional Coating conforms to the following
SSPC standards:
| SSPC 15 |
SSPC 22 |
SSPC 13.01 |
SSPC 14.01 |
paint 28 |
To the best of our knowledge the technical
data contained here in is true and accurate on the date of publication
and is subject to change without prior notice. User must contact
IAG to verify correctness before specifying or ordering. No guarantee
or accuracy is given or implied. We guarantee our product to
conform to IAG quality control. We assume no responsibility for
coverage, performance or injuries resulting from use. Liability,
if any, is limited to replacement of products. NO OTHER WARRANTY
OR GUARANTEE OF ANY KIND IS MADE BY IAG, EXPRESS OR IMPLIED,
STATUTATORY, BY OPERATION OF LAW OR OTHERWISE, INCLUDING MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. June
2003
|
