IAG Fire Retardant Coating
IAG products are a high performance thin film fire retardant
coating. It has been formulated to retard the flame spread across
a wide variety of materials as well as suppress the generation
of smoke.
This proprietary flame retardant two-part epoxy coating creates
a highly adherent fire retardant barrier on woods, metals, concrete,
plastics and insulating foams. It may be used to overcoat lead
and asbestos.
Flame spread classifications were developed by Underwriters
Laboratories and adopted by many building codes. The classifications
are based on the numerical scale ranging from 0-25 for a class
I rating.
The smoke generation indices are based upon the amount of
visible smoke detected when a material burns.
Flame spread requirements for building materials within code
are intended to delay fire growth, providing occupants more time
to escape the area and provide firefighters time to respond.
IAG products were tested to the ASTME-84 standard by an independent
laboratory. IAG products achieved a Class I flame spread and
a Class I smoke rating. A copy of the report is available upon
request.
In the event of fire, IAG coatings produces water and gases,
which snuff out oxygen and provides a cooling effect at the flame
front. A dense char is formed, which further protects the surface
from combustion.
IAG coatings may be sprayed directly from the container, after
proper mixing, using standard airless equipment.
Surfaces must be prepared according to SSPC standards. Please
review the application guide and material safety data sheets
prior to use.
FEATURES:
No VOC's
Non-halogenated
Chemically resistant
Water resistant
Excellent adhesion
Flexible
DOT non-hazardous
TYPICAL PROPERTIES:
| Color |
gray |
| Viscosity @ 25 C |
7,000 |
| Tensile Strength |
7,600 psi |
| Open Time |
50 min |
| Operating Temp C |
-50 to + 140 |
| Hardness, Shore D |
78 |
| Mix ratio by weight (A:B) |
100:30 |
| Mix ratio by volume (A:B) |
100:35 |
Direct UV Exposure Applications should be top coated
with a pigmented urethane.
To the best of our knowledge the technical
data contained here in is true and accurate on the date of publication
and is subject to change without prior notice. User must contact
IAG to verify correctness before specifying or ordering. No guarantee
or accuracy is given or implied. We guarantee our product to
conform to IAG quality control. We assume no responsibility for
coverage, performance or injuries resulting from use. Liability,
if any, is limited to replacement of products. NO OTHER WARRANTY
OR GUARANTEE OF ANY KIND IS MADE BY IAG, EXPRESS OR IMPLIED,
STATUTATORY, BY OPERATION OF LAW OR OTHERWISE, INCLUDING MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. June
2003
|
